TMP đại lý phân phối sản phẩm Nireco tại Việt Nam
Web Control Systems
Edge Position Control Systems(Electric type)
Motor-Driven Actuator A352
Overview
The A352-150-20 AC servo actuator is connected to a servo driver and a strip guide amplifier. This model is primarily used as an actuator (drive) for EPC systems. The totally enclosed structure of the actuator combines a highly efficient ball screw and an AC servo motor. The ball screw is driven by the forward or reverse rotation of the AC servo motor. The ball screw nut moves in the direction of the thrust, generating an external reciprocating motion.
Specifications
| Model | A352-150-20 |
|---|---|
| Nominal speed | Approx. 20 mm/s (at a motor speed of 2,000 rpm) |
| Mechanical stroke | 150 mm * stroke between the reed switches |
| Usable stroke | 140mm * stroke between the reed switche |
| Thrust | 3.5 kN |
| Motor specifications | Output 0.2 kW Voltage 200 V AC |
| Lubrication | Grease applied |
| Piston rod rotational torque | Approx. 6 N‧m |
| Ambient operating temperature | 0 to 40℃ (standard) (If this unit is to be used at a temperature of 40℃ or greater, please contact your nearest Nireco Web Sales Section.) |
| Relative humidity | No more than 80%RH |
| Protective structure rating | Indoor type (corresponding to IP50 protection) |
| Mass | 23kg |
| Paint color (standard color) | 7.5BG 4/1.5 |
Motor điều chỉnh canh biên A352 Nireco Việt Nam
